Rotary Disc Vacuum Filter Solid-Liquid Separator Sludge Dewatering Equipment
Brief Description
The filter cloth of the rotary disk filter has excellent corrosion resistance and wear resistance. For wastewater containing acid-base and high-concentration impurities, special material filter cloth can be selected to extend service life, reduce filter cloth replacement frequency, and lower equipment maintenance costs.
Product Parameters
Turntable filter machines are primarily used for cooling water treatment and advanced wastewater reuse. For cooling water and circulating water filtration and reuse, the inlet water quality must be below 80 mg/L, and the outlet water quality must be below 20 mg/L. For advanced wastewater treatment, it can be installed after conventional activated sludge processes, delayed aeration processes, SBR systems, oxidation ditches, trickling filters, and oxidation ponds.
| Parameter |
Value |
| Processing flow |
28~35m³/h (single disk) |
| Filter plate diameter |
2000mm |
| Number of filter plates |
3-23 |
| Filtration area |
4.5m²/single disc |
| Filtration rate |
8-15m/h/m² |
| Influent water quality |
SS≤30mg/L |
| Outlet water quality |
SS≤10mg/L |
| Filter disc material |
Reinforced engineering plastic |
| Filter cloth material |
Stainless steel, PE polyester |
| Body material |
Stainless steel |
| Backwash drive power |
1.5KW |
| Backwash pump power |
5-11KW |
| Washing water volume |
30L/1 tray/1 time |
| Cleaning pressure |
6-8 bar |
| Head loss |
50-200mm |
| Backwash cycle |
1-3min (or continuous) |
Advantages
- Continuous operation: 24-hour operation without stopping for backwash
- Excellent treatment efficiency with 10 micron filtration capability
- Low backwash water consumption (1%-2% of total inlet water volume)
- Low head loss (0.05-0.25 m³)
- Low operating costs (less than 0.01 yuan per ton of water)
- Low installed power requirements
- Fully automated operation with program-controlled functions
- Compact footprint with vertical design
- Short design and construction cycle with modular design
Company Introduction
Jiangsu Ponis Environmental Technologies Co., Ltd. covers a total area of 10000 square meters with two production facilities. Our management includes technical, finance, engineering, and production departments with a fully equipped experimental center. We offer complete product design, manufacturing, and debugging services with customized equipment solutions and operational support.
FAQ
Are You Trading Company Or Manufacture?
We are both manufacturer and trading company with over 15 years' professional experience in wastewater treatment equipment manufacturing and engineering services.
What Are Your Main Products?
Automatic dosing machine, sludge dewatering machine, mechanical bar screen, screw conveyor, sludge scraper, filter press machine, sewage gates, aerator equipment, mixing machine, turntable filter machine, bag dust collector, dissolved air flotation equipment, etc.
How Can I Find The Suitable Model?
Please provide flow rate, solids content and sludge type, we can assist you in model selection.
Do You Offer After-Sales Service?
Video technical support, online support, spare parts, field maintenance repair service.
Do You Provide OEM Service?
Yes. We can do customized design according to your different request for sludge dewatering.
What About Your Produce Time? What Kind Of Transportation Do You Offer?
Within 30 days against down payment. Air, land & sea transportation available.
What Kind Of Payment Do You Accept?
T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, Money Gram.
