Energy Saving Rotary Disc Filter Continuous Operation with Auto Cleaning
Product Description
Compared with traditional filtration equipment, the rotary disk filter has a higher filter disk utilization rate. Multiple groups of filter disks rotate synchronously, performing filtration and cleaning operations simultaneously with no shutdown waiting time, significantly increasing processing capacity per unit time to meet high-flow processing demands.
Product Parameters
Turntable filter machines are primarily used for cooling water treatment and advanced wastewater reuse. For cooling water and circulating water filtration and reuse, the inlet water quality must be below 80 mg/L, and the outlet water quality must be below 20 mg/L. For advanced wastewater treatment, it can be installed after conventional activated sludge processes, delayed aeration processes, SBR systems, oxidation ditches, trickling filters, and oxidation ponds.
| Parameter |
Value |
| Processing flow |
28~35m³/h (single disk) |
| Filter plate diameter |
2000mm |
| Number of filter plates |
3-23 |
| Filtration area |
4.5m²/single disc |
| Filtration rate |
8-15m/h/m² |
| Influent water quality |
SS≤30mg/L |
| Outlet water quality |
SS≤10mg/L |
| Filter disc material |
Reinforced engineering plastic |
| Filter cloth material |
Stainless steel, PE polyester |
| Body material |
Stainless steel |
| Backwash drive power |
1.5KW |
| Backwash pump power |
5-11KW |
| Washing water volume |
30L/1 tray/1 time |
| Cleaning pressure |
6-8 bar |
| Head loss |
50-200mm |
| Backwash cycle |
1-3min (or continuous) |
Advantages
- Continuous operation: 24-hour operation without stopping for backwash
- Excellent treatment efficiency with 10 micron filter cloth pore size
- Low backwash water consumption (1%-2% of total inlet water volume)
- Low head loss (0.05-0.25 m³)
- Low operating costs (less than 0.01 yuan per ton of water)
- Low installed power requirements
- Fully automated operation with program-controlled functions
- Compact footprint with vertical design
- Short design and construction cycle with modular design
Company Introduction
Jiangsu Ponis Environmental Technologies Co., Ltd. covers a total area of 10,000 square meters with two factories for production and assembly. Our management oversees technical, finance, engineering, production departments, and an experimental center. From product design to manufacturing and debugging, we maintain mature processes and stable supply. Our experimental center features complete equipment for pollutant analysis and simulated operating conditions including physicochemical, biochemical, and advanced treatment processes. We offer customized equipment manufacturing and provide operational support.
Frequently Asked Questions
Q: Are You Trading Company Or Manufacture?
A: We are both manufacturer and trading company with over 15 years' professional experience in wastewater treatment equipment manufacturing and engineering services.
Q: What Are Your Main Products?
A: Our product range includes automatic dosing machines, sludge dewatering machines, mechanical bar screens, screw conveyors, sludge scrapers, filter press machines, sewage gates, aerator equipment, mixing machines, turntable filter machines, bag dust collectors, and dissolved air flotation equipment.
Q: How Can I Find The Suitable Model?
A: Please provide flow rate, solids content and sludge type for our assistance in model selection.
Q: Do You Offer After-Sales Service?
A: We provide video technical support, online assistance, spare parts, and field maintenance repair services.
Q: Do You Provide OEM Service?
A: Yes, we offer customized designs according to your specific requirements for sludge dewatering.
Q: What About Your Produce Time? What Kind Of Transportation Do You Offer?
A: Production typically completes within 30 days after down payment. We arrange air, land, and sea transportation.
Q: What Kind Of Payment Do You Accept?
A: We accept T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, and Money Gram.
