Fully Automatic Rotary Disc Vacuum Filter Intelligent Discharge Ceramic Disc Filter

Large Image : Fully Automatic Rotary Disc Vacuum Filter Intelligent Discharge Ceramic Disc Filter

Product Details:

Place of Origin:	CHINA
Brand Name:	Ponis
Certification:	CE,UL
Model Number:	Drum Filter Machine

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Export Packing
Delivery Time:	30 DAYS
Payment Terms:	L/C,T/T
Supply Ability:	10 Pcs/Month

Contact Now Chat Now

Fully Automatic Rotary Disc Vacuum Filter Intelligent Discharge Ceramic Disc Filter

Description

Product Name:	Drum Filter Machine	Filter Cloth Pore Size:	10 Microns
Control Method:	Fully Automatic	Processing Flow:	28~35m3/h (single Disk)
Filter Plate Diameter:	2000mm	Operating Hours:	24 Hours Continuous Operation
Highlight:	disc vacuum filter intelligent , discharge ceramic disc filter , automatic disc vacuum filter

Fully Automatic Rotary Disc Vacuum Filter Intelligent Discharge Ceramic Disc Filter

Product Overview

The Rotary Disk Vacuum Filter is a high-efficiency solid-liquid separation system that captures impurities through rotating filter disks. With its compact design and minimal footprint, this equipment is ideal for municipal sewage and industrial wastewater treatment applications, significantly improving water quality while reducing subsequent processing costs.

Technical Specifications

Parameter	Specification
Processing Flow	28~35m³/h (single disk)
Filter Plate Diameter	2000mm
Number of Filter Plates	3-23
Filtration Area	4.5m²/single disc
Filtration Rate	8-15m/h/m²
Influent Water Quality	SS≤30mg/L
Outlet Water Quality	SS≤10mg/L
Filter Disc Material	Reinforced engineering plastic
Filter Cloth Material	Stainless steel, PE polyester
Body Material	Stainless steel
Backwash Drive Power	1.5KW
Backwash Pump Power	5-11KW
Washing Water Volume	30L/1 tray/1 time
Cleaning Pressure	6-8 bar
Head Loss	50-200mm
Backwash Cycle	1-3min (or continuous)
Working Pressure	Gravity filtration (or continuous)
Filtration Form	Cement tank type, box type

Key Advantages

Continuous 24-hour operation with no downtime for backwashing
Exceptional treatment efficiency with 10-micron filtration capability
Minimal backwash water consumption (1%-2% of total inlet)
Low head loss (0.05-0.25 m³) and operating costs (<0.01 yuan/ton)
Compact vertical design maximizes filtration area in minimal space
Fully automated operation with program-controlled functions
Modular design facilitates quick installation and future expansion

Manufacturer Profile

Jiangsu Ponis Environmental Technologies Co., Ltd. operates from a 10,000 square meter facility with dedicated production and assembly areas. Our comprehensive operation includes technical, engineering, and production departments supported by a fully equipped experimental center capable of complete pollutant analysis and process simulation. We offer customized equipment solutions with full operational support and debugging services.

Frequently Asked Questions

Are you a manufacturer or trading company?

We are both manufacturer and trading company with over 15 years' experience in wastewater treatment equipment manufacturing and engineering services.

What are your main products?

Our product range includes automatic dosing machines, sludge dewatering equipment, mechanical bar screens, screw conveyors, filter press machines, aerators, mixing equipment, and various water treatment systems.

How can I select the appropriate model?

Please provide flow rate, solids content and sludge type for our technical team to recommend the optimal configuration.

What after-sales services do you provide?

We offer comprehensive support including video technical assistance, online troubleshooting, spare parts supply, and field maintenance services.

Do you offer OEM services?

Yes, we provide customized design solutions for all sludge dewatering requirements.

What are your production lead times and shipping options?

Standard production time is within 30 days after deposit. We ship via air, land and sea transportation worldwide.

What payment methods do you accept?

We accept T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, and MoneyGram.
