Mechanical Bar Screen 600-2600mm Width 1-5mm Gap
Product Specifications
| Attribute |
Value |
| Product Name |
Mechanical Bar Screen |
| Equipment width |
600-2600mm |
| Channel width |
620-2640mm |
| Gap between grizzly bars |
1-5mm |
| Installation angle |
35° |
| Speed of rotation |
≈6r/min |
Fully Automatic Mechanical Bar Screen
Super efficient intercept suspended and floating objects in wastewater treatment applications.
Product Overview
The mechanical bar screen is a pretreatment equipment for solid-liquid separation, primarily installed at water inlets of sewage treatment plants, pumping stations, and similar facilities. Its core function is to intercept larger suspended and floating objects in water, including branches, plastics, and domestic waste, protecting downstream equipment from blockage or damage. Available in coarse and fine screen configurations based on bar spacing.
Technical Operation
This drum spiral type equipment features a round screening drum installed at a 35° angle to the horizontal plane. As sewage flows into the drum, debris larger than the screen gap is intercepted and collected on the inner surface. The motor-driven rotation, combined with a screening removal brush and flushing mechanism, ensures continuous cleaning. Collected screenings are conveyed via screw rod to a material box or conveyor for disposal after dewatering.
Key Advantages
- Compact design with small footprint for easy installation and maintenance
- Adjustable bar spacing from 1mm to 5mm for precise screening
- High interception efficiency with enclosed conveyance to prevent environmental contamination
- Fully automatic operation with low energy consumption and noise levels
- Continuous self-cleaning mechanism prevents clogging during operation
Manufacturer Profile
Jiangsu Ponis Environmental Technologies Co., Ltd. operates from a 10,000 square meter facility with dedicated production and assembly areas. Our comprehensive organization includes technical, engineering, and production departments supported by a fully equipped experimental center. We offer complete solutions from design to manufacturing and operational support, with capabilities for custom equipment development and performance testing under simulated operating conditions.
Frequently Asked Questions
Are you a trading company or manufacturer?
We are both manufacturer and trading company with over 15 years' experience in wastewater treatment equipment manufacturing and engineering services.
What are your main products?
Our product range includes automatic dosing machines, sludge dewatering equipment, mechanical bar screens, screw conveyors, sludge scrapers, filter presses, sewage gates, aeration equipment, mixing machines, turntable filters, bag dust collectors, and dissolved air flotation systems.
How can I select the appropriate model?
Please provide flow rate, solids content, and sludge type for our technical team to recommend the optimal configuration.
Do you offer after-sales service?
Our comprehensive support includes video technical assistance, online support, spare parts supply, and field maintenance services.
Do you provide OEM services?
Yes, we offer customized designs to meet specific sludge dewatering requirements.
What is your production lead time and shipping options?
Standard production time is within 30 days after down payment. We arrange transportation by air, land, and sea worldwide.
What payment methods do you accept?
We accept T/T, L/C, Paypal, cash, D/P, D/A, Western Union, and MoneyGram.
