Chain and Flight Rake Screen - Stable Operation, Simple Maintenance, Long Service Life
Mechanical grilles used in industrial wastewater treatment are often made of special corrosion-resistant materials (such as 316L stainless steel) to adapt to wastewater containing acids, alkalis, or other corrosive substances, extending the service life of the equipment in harsh working environments.
Product Specifications
This equipment is of drum spiral type. The round screening drum is used as the screen surface and it is installed in the canal by 35° with horizontal plane. When the sewage flows into the screening drum from the screen end, the dregs larger than the screen gap are intercepted and settled on the inner surface of screening drum. The rotation of whole screening drum is driven by motor. The screening removal brush on the top of screening drum cleans off the screening surface with flushing mechanism. The screening is flushed into the central material groove and lifted up by conveying screw rod. The screening drops off in the material box or conveyor for transportation out for further discharging port after squeezing and dewatering.
Key Advantages
- Compact structure of whole machine, small floor area, easy installation and operation as well as maintenance
- Small gap between grizzly bars of equipment, the gap will be designed 1mm-5mm
- High trash interception efficiency, enclosed conveyance and no environment pollution
- The equipment can be designed fully automatic control, smooth operation, low energy consumption and low noise
- The equipment can be self-cleaning during operation process, never being clogged
Manufacturer Information
Jiangsu Ponis Environmental Technologies Co., Ltd. covers a total area of 10000 square meters and is divided into two factories based on production and assembly. The management office has jurisdiction over the technical department, finance department, engineering department, production department, and an experimental center. From product design to manufacturing debugging, the mode is mature and the supply is stable. Our experimental center has complete equipment, which can perform trace and complete analysis of pollutants, and also has simulated operating conditions such as physicochemical, biochemical, and advanced treatment. The company can customize and manufacture equipment for customers, as well as provide guarantees for their later operation and debugging.
Frequently Asked Questions
Are You Trading Company Or Manufacture?
We Are Both Manufacture And Trading Company. We Have Over 15 Years' Professional Experience As a Waste Water Treatment Equipment Manufacturer And Engineering Service Enterprise.
What Are Your Main Products?
Automatic dosing machine, sludge dewatering machine, mechanical bar screen, screw conveyor, sludge scraper, filter press machine, sewage gates, aerator equipment, mixing machine, turntable filter machine, bag dust collector, dissolved air flotation equipment, etc.
How Can I Find The Suitable Model?
Please Provide Flow Rate, Solids Content And Sludge Type, We Can Assist You In Model Selection.
Do You Offer After-Sales Service?
Video Technical Support, Online Support, Spare Parts, Field Maintenance Repair Service.
Do You Provide OEM Service?
Yes. We Can Do The Customized Design According To Your Different Request for sludge Dewatering.
What About Your Produce Time? What Kind Of Transportation Do You Offer?
Within 30 Days Against Down Payment. Air, Land & Sea.
What Kind Of Payment Do You Accept?
T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, Money Gram.
