Handling 40-60m³/H Slurry Dewatering Machine Low Noise With 3.0kw Motor For Mining Contains

Slag sludge from mining contains a large number of solid particles, so sludge dewatering machines for this purpose need to have strong wear resistance. The internal components of the equipment that come into contact with sludge are made of wear-resistant alloy materials, which can withstand particle friction, extend the service life, and efficiently separate moisture to recover slag for resource reuse.

This equipment consists of belt concentrator and dewaterer. The sludge is mixed and reacted sufficiently in the sludge mixer after the focculant is added. Afterwards, the sludge flows into the gravity dewaterning section. Alot of free water in the sludge flows out of the gap offiter belt under the action of gravity and the free water enters into the water collection tank. Aferwards, it is guided by wedge precompressionsection so that the sludge is leveled gradully and it is dewatered further after slight squeezing. Then, the sludge enters into S-shape multi-rolsqueezing section and it is clamped in the middle between upper layer of fiter cloth and lower layer of flter cloth. The sludge is squeezed repeatedly by severalrolls in diferent diameters. As this time, the sludge is sheared to faciliate the sludge to dewater further to form the cake. Finally, the scraper is used to scrape down the cake and transport out the cake. The upper and lower filtet belt can be reused after washing.

• Stepless regulating motor drive can regulate the running speed at any time and it has strong adaptablility
• The specially-made flushing nozzle and clogging-prevention device will flush off the filter belt
• The T-shape water leakage groove is used in the dewatering head roll to squeeze off the water to flow out quickly
• The gravity dewatering section is of indlined design. The static head of sludge is enlarged to enhance the dewatering effect so that the sludge can be thickened sufficiently before squeezing
• Compact structure of whole machine, automactic deviation rectification ofiter belt, low operation noise, power consumption saving, less chemicals consumption, good dewatering effect and low operation expense

Jiangsu Ponis Environmental Technologies Co., Ltd. covers a total area of 10000 square meters and is divided into two factories based on production and assembly. The management office has jurisdiction over the technical department, finance department, engineering department, production department, and an experimental center. From product design to manufacturing debugging, the mode is mature and the supply is stable.

Our experimental center has complete equipment, which can perform trace and complete analysis of pollutants, and also has simulated operating conditions such as physicochemical, biochemical, and advanced treatment. The company can customize and manufacture equipment for customers, as well as provide guarantees for their later operation and debugging.

A: We Are Both Manufacture And Trading Company. We Have Over 15 Years' Professional Experience As a Waste Water Treatment Equipment Manufacturer And Engineering Service Enterprise.

A: Automatic dosing machine, slude dewatering machine, mechanical bar screen, screw conveyor, sludge scraper, fliter press machine, sewage gates, aerator equipment, mixing machine, turntable filter machine, bag dust collector, dissolved air flotation equipment, etc.

A: Please Provide Flow Rate, Solids Content And Sludge Type, We Can Assist You In Model Selection.

A: Video Technical Support, Online Support, Spare Parts, Field Maintenance Repair Service.

A: Yes. We Can Do The Customized Design According To Your Different Request for sludge Dewatering.

A: Within 30 Days Against Down Payment. Air, Land & Sea.

A: T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, Money Gram.
